Specifications
Door Preparation:Cross bore 2-1/8", edge bore 1", 1"x2-1/4" latch mortise.
Backset: 2-3/8" or 2-3/4"
Door Thickness:1-3/8" tp 1-3/4"
Cylinder: KW1 standard, SC1 available, 5pin
Chassis:Cylindrical
Faceplate: 2-1/4" Rround corner, drive-in available
Strikes: 2-1/4" full rim standard for entry, 2-1/4" full lip standard for interior, others available
Bolt: 1/2" Throw
Door Handing: All hardware is reversible for left or righthanded doors except the Glenshaw entrylevers in contractor boxes or Glenshawdummy levers. These need to be specifiedfor left or right handed doors.
